Normal: 93 D prints per hour Line Drawing: 72 D prints per hour Best Drawing: 30 ft²/hr Image Draft 400 ft²/hr
Paper Handling
Maximum Paper Width
24.0" (610 mm)
Maximum Printable Area
24.0" x 300.0' (610 mm x 91.44 m)
Margins
Sheet: 0.2 x 0.67 x 0.2 x 0.2" (5 x 17 x 5 x 5 mm) Roll: 0.2 x 0.2 x 0.2 x 0.2" (5 x 5 x 5 x 5 mm)
Paper Sizes
Sheet: 8.26 x 11.0 to 24.0 x 66.0" (210 x 279 to 610 x 1676 mm ) Roll: 11.0 to 24.0" (279 to 610 mm) rolls
Paper Types
Bond And Coated Paper: bond, coated, heavyweight coated, super heavyweight plus matte Technical Paper: natural tracing, translucent bond, vellum Film: clear, matte Photographic Paper: satin, gloss, semi-gloss, matte, high-gloss Self-Adhesive: polypropylene, vinyl
Special Media Support
Technical paper, film, self-adhesive paper
Media Weight
60 to 328 g/m²
Media Thickness
Up to 0.8 mm (31.5 mil)
Maximum Media Roll Diameter
5.3" (134.62 mm) external diameter
Maximum Roll Print Length
300.0' (91 m)
Paper-Feed Method
Sheet feed, roll feed, automatic cutter
Connectivity
Computer Interface
Fast Ethernet (100Base-T), Hi-Speed USB 2.0 certified, EIO Jetdirect accessory slot
Printer Language
Adobe PostScript 3, Adobe PDF 1.7, HP-GL/2, TIFF, JPEG, CALS G4, HP PCL 3 GUI
Drivers
HP-GL/2, HP-RTL drivers for Windows (optimized for AutoCAD 2000 and higher); HP PCL 3 GUI driver for Mac OS X; PostScript Windows, Linux, and Mac drivers
Network Capable
Fast Ethernet (100Base-T)
OS Compatibility
Microsoft: Windows 7 Ultimate/Professional/Home Premium, Windows Vista Ultimate/Business/Home Premium, Windows XP (32-bit, 64-bit) Professional/Home, Windows Server 2008 (32-bit, 64-bit), Windows Server 2003 (32-bit, 64-bit) Mac: OS X v 10.5, v 10.6 Citrix: XenApp, XenServer Linux
Windows System Requirements
Windows XP: (SP2 or later) Intel Pentium family or AMD K6/Athlon/Duron family (1 GHz) 1 GB RAM 2 GB available hard disk space Windows Vista: 32-bit (x86) or 64-bit (x64) processor (1 GHz) 2 GB RAM 2 GB available hard disk space
Apple System Requirements
OS X v 10.4, OS X v 10.5 PowerPC G4, G5, or Intel Core Processor 1 GB RAM 2 GB available hard disk space
Environmental
Temperature
Operating Temperature: 41 to 104 ºF (5 to 40 °C) Storage Temperature: -13 to 131 ºF (-25 to 55 ºC )
Humidity
Operating Humidity: 20 to 80% RH Storage Humidity: 0 to 95% RH
Acoustic Noise
Sound Pressure: active - 46 dB(A); standby - 29 dB(A) Sound Power: active - 6.3 B(A); standby - 4.4 B(A)
